NUR6C04BU-C
Copper cable, category 6 UTP, CMR, 4-pair, conductors are 24 AWG, twisted in pairs, separated by an integrated pair divider and protected by a flame retardant PVC jacket, blue.
Available in Latin America region only. Pallets are configured in 2 layers, 10 cartons per layer, total of 20 cartons per pallet.
| Note | Available in Latin America region only. Pallets are configured in 2 layers, 10 cartons per layer, total of 20 cartons per pallet. |
| AWG Size | 24 |
| Length (ft.) | 1000 |
| Length (m) | 305 |
| Nominal Diameter (In.) | 0.222 |
| Nominal Diameter (mm) | 5.6 |
| Jacket Material | CMR – Flame retardant PVC |
| No. of Pairs | 4 |
| Packaging Type | Easy-payout box |
| CE Compliant | No |
| Application | Ethernet 10BASE-T, 100BASE-T (Fast Ethernet), and 1000BASE-T (Gigabit Ethernet), 155 Mb/s ATM, 622 Mb/s, ATM, 1.2 Gb/s ATM, Token ring 4/16 |
| Cable Type | UTP |
| Flammability Rating | PVC (CMR) – UL 1666 |
| Part Features | Descending length cable markings – easy identification of remaining cable reduces installation time and cable scrap, Easy payout reel – ensures proper performance and provides quick installation |
| Weight (Kg) | 13/305m |
| Weight (lbs) | 28/1000 ft. |
| RoHS Compliancy Status | RoHS directive is not applicable |
