ÖLFLEX® DC 100

Colour-coded cable for the power supply of plants with DC grids

ÖLFLEX® DC 100 – colour-coded power cable for DC applications up to 0,75/1,5 kV DC

Designed for DC applications in industrial environment with color code acc. EN 60445

Suitable for outdoor use UV-resistant

CE

Benefits

  • Specially constructed for the long term operation with DC voltage up to 0,75 / 1,5 kV
  • Suitable for the construction of energy efficient DC grids in industrial plants

Application range

  • Plant engineering
    Industrial machinery
    Heating and air-conditioning systems
    Power stations
    Stage applications
  • For plants where power is supplied by a direct current network
  • For fixed installation as well as occasional flexing at free, non-continuously recurring movement without tensile load

Product features

  • Flame-retardant according IEC 60332-1-2
  • UV and weather-resistant according to ISO 4892-2
  • Ozone-resistant according to EN 50396

Product Make-up

  • Fine-wire strand made of bare copper wires
  • Core insulation: special PVC
  • Core colors: red (L+), white (L-), green-yellow
  • PVC outer sheath, black (similar RAL 9005)

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000057
  • ETIM 5.0 Class-Description: Low voltage power cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000057
  • ETIM 6.0 Class-Description: Low voltage power cable

Core identification code

  • red, white, green-yellow

Conductor stranding

  • Fine wire according to VDE 0295,
    class 5/IEC 60228 class 5

Minimum bending radius

  • Occasional flexing: 15 x outer diameter
  • Fixed installation: 4 x outer diameter

Nominal voltage

  • DC (core-ground): max. 0,75 kV
    DC (core-core): max. 1,5 kV

Test voltage

  • 4000 V

Protective conductor

  • G = with GN-YE protective conductor
  • X = without protective conductor

Temperature range

  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C
  • Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon request.
  • Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related surcharges.
  • Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
  • Packaging size: coil ≤ 30 kg or ≤ 250 m, otherwise drum
  • Please specify the preferred type of packaging (e.g. 1 x 500 m drum or 5 x 100 m coils).
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Article number Number of cores and mm² per
conductor
Outer diameter [mm] Copper index (kg/km) Weight (kg/km)
11101106 3 G 1.5  8.7 43 134.2
11101107 3 G 2.5  10 72 188.2
11101108 3 G 4.0  11.4 115 263.4
11101109 3 G 6.0  12.6 173 346.2
11101111 3 G 16.0  18.3 461 823.8
11101113 3 G 25.0  23 720 1071
11101114 3 G 35.0  25.6 1008 1684
