ÖLFLEX® CLASSIC 110 H SF

Halogen-free control cable, EN 45545-2 certified, oil resistant and very flexible

ÖLFLEX® CLASSIC 110 H – halogen-free control cable, HFFR, oil-resistant, very flexible and cold-resistant down to -30°C for various applications, EN 45545-2 certified for railway/rolling stock application

  • EN 45545-2 HL1, HL2, HL3
  • High flexibility and oil-resistance
  • Other sizes on request

Rail Good chemical resistance Flame-retardant Halogen-free Cold-resistant Oil-resistant Temperature-resistant UV-resistant

CE

Benefits

  • Easy handling and installation due to very flexible cable type
  • Wide application range due to excellent product features
  • EN 45545-2 certified for rolling stock applications

Application range

  • Railway applications
  • Public buildings like airports or railway stations
  • Plant engineering, Industrial machinery
    Heating and air-conditioning systems
    Stage applications
  • Particularly where human and animal life as well as valuable property are exposed to high risk of fire hazards

Product features

  • Flame-retardant according to IEC 60332-1-2
    (flame spread on a single cable)
  • No flame-propagation according to IEC 60332-3-24 respectively IEC 60332-3-25 (Flame spread on vertical cable or wire bundle)
  • Halogen-free according to IEC 60754-1
    (amount of halogen acid gas)
    Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity)
  • Low smoke density according to IEC 61034-2
  • Oil-resistant according to EN 50363-4-1 (TM5)
    and UL OIL RES I and UL OIL RES II
  • UV and weather-resistant according to ISO 4892-2
  • Ozone-resistant according to EN 50396

Norm references / Approvals

  • EN 45545-2 HL1, HL2, HL3
  • Based on EN 50525-3-11
  • Based on EN 50525-2-51

Product Make-up

  • Extra-fine wire strand made of bare copper wires
  • Core insulation: Halogen-free
  • Cores twisted in layers
  • Outer sheath: Special halogen-free compound, black

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000104
  • ETIM 5.0 Class-Description: Control cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000104
  • ETIM 6.0 Class-Description: Control cable

Core identification code

  • Black with white numbers acc. to VDE 0293-334

Conductor stranding

  • Extra-fine wire according to VDE 0295, class 6/IEC 60228 class 6

Minimum bending radius

  • Occasional flexing: 10 x outer diameter
  • Fixed installation: 4 x outer diameter

Nominal voltage

  • U0/U: 300/500 V

Test voltage

  • 4000 V

Protective conductor

  • G = with GN-YE protective conductor
  • X = without protective conductor

Temperature range

  • Occasional flexing: -30°C to +70°C
  • Fixed installation: -40°C to +80°C
Article number  Number of cores and mm² per
conductor
Outer diameter [mm]  Copper index (kg/km)  Weight (kg/km)
1002140 5 G 0.5  6.3 24 83
1002141 3 G 1.0  6.1 28.8 75
1002142 5 G 1.0  7.3 48 123
1002143 7 G 1.0  8.1 67.2 159
1002144 13 G 1.0  11.4 124.8 295
1002145 25 G 1.0  15 240 515
1002146 43 G 1.0  19.8 412.8 899
1002147 73 G 1.0  25.3 700.8 1402
1002148 3 G 1.5  6.8 43.2 96
1002149 5 G 1.5  8.3 72 163
1002150 7 G 1.5  9 100.8 208
1002151 13 G 1.5  13 187.2 394
1002152 25 G 1.5  17.2 360 704
1002153 43 G 1.5  22.6 619.2 1198
1002154 61 G 1.5  25.6 878.4 1637
1002155 3 G 2.5  8.3 72 147
1002156 5 G 2.5  10.1 120 255
1002157 7 G 2.5  11.2 168 333
1002158 3 G 6.0  11.7 172.8 321
1002159 5 G 6.0  14.5 288 541
1002160 7 G 6.0  16 403.2 712
1002161 5 G 10.0  18.4 480 915
1002162 5 G 16.0  22.3 768 1344
1002163 5 G 35.0  31.1 1680 2778
