Dây Cáp Điều Khiển LAPP KABEL ÖLFLEX® CLASSIC 128 H BK 0,6/1 kV, -40°C to +80°C, BLACK | Chính Hãng – Giá Tốt Nhất
Hãng sản xuất: LAPP KABEL
Xuất xứ thương hiệu: Germany
(Giấy tờ: CO,CQ,BIL,PACKING LIST, TỜ KHAI đầy đủ)
LAPP KABEL ÖLFLEX® CLASSIC 128 H BK 0,6/1 kV là dòng cáp điện và cáp điều khiển không halogen, sử dụng ruột đồng trần nhiều sợi mảnh, thiết kế mềm dẻo giúp dễ thi công và tiết kiệm không gian nhờ đường kính cáp nhỏ. Cáp có vỏ ngoài hợp chất đặc biệt không halogen màu đen, chống cháy, không lan truyền lửa, ít khói, chịu UV, thời tiết và ozone. Sản phẩm phù hợp cho tòa nhà công cộng, nhà máy, máy móc công nghiệp, hệ thống điều hòa – HVAC và các khu vực yêu cầu cao về an toàn cháy nổ, đồng thời thích hợp sử dụng ngoài trời.
ÖLFLEX® CLASSIC 128 H BK 0,6/1 kV
Cost-effective halogen-free control cable with improved fire characteristics, 0,6/1kV
ÖLFLEX® CLASSIC 128 H BK 0,6/1 kV Power and Control Cable, halogen-free/ highly flame retardant, HFFR, flexible, conductor class 5, public buildings
- For space-saving and cost-effective installation
- For use within public buildings and industrial plants
- UV and weather-resistant according to ISO 4892-2
Benefits
- Space-saving installation due to small cable diameters
- Easy handling and installation due to flexible design
Application range
- Public buildings
- Plant engineering
Industrial machinery
Heating and air-conditioning systems - Particularly where human and animal life as well as valuable property are exposed to high risk of fire hazards
- Suitable for outdoor applications
Product features
- Flame-retardant according to IEC 60332-1-2
(flame spread on a single cable) - No flame-propagation according to IEC 60332-3-24 respectively IEC 60332-3-25 (Flame spread on vertical cable or wire bundle)
- Halogen-free according to IEC 60754-1
(amount of halogen acid gas)
Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity) - Low smoke density according to IEC 61034-2
- UV and weather-resistant according to ISO 4892-2
- Ozone-resistant according to EN 50396
Norm references / Approvals
- Based on EN 50525-3-11
Product Make-up
- Fine-wire strand made of bare copper wires
- Core insulation: Halogen-free
- Outer sheath made of special halogen-free coumpound, black
Technical Data
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000057
- ETIM 5.0 Class-Description: Low voltage power cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000057
- ETIM 6.0 Class-Description: Low voltage power cable
Core identification code
- Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
- From 6 cores: black with white numbers
Conductor stranding
- Fine wire according to VDE 0295 Class 5/ IEC 60228 Class 5
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 600/1000 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Number of cores and mm² per conductor | Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) | |
|---|---|---|---|---|---|
|
1123520
|
2 X 1.0 | 7.4 | 19.2 | 76 | |
|
1123521
|
3 G 1.0 | 7.8 | 28.8 | 101 | |
|
1123522
|
4 G 1.0 | 8.4 | 38.4 | 120 | |
|
1123523
|
5 G 1.0 | 9.2 | 48 | 143 | |
|
1123524
|
7 G 1.0 | 9.9 | 67.2 | 179 | |
|
1123525
|
12 G 1.0 | 12.8 | 115.2 | 283 | |
|
1123528
|
2 X 1.5 | 8.4 | 28.8 | 112 | |
|
1123529
|
3 G 1.5 | 8.9 | 43.2 | 135 | |
|
1123530
|
4 G 1.5 | 9.6 | 57.6 | 163 | |
|
1123531
|
5 G 1.5 | 10.5 | 72 | 196 | |
|
1123532
|
7 G 1.5 | 11.4 | 100.8 | 253 | |
|
1123533
|
12 G 1.5 | 15.1 | 172.8 | 396 | |
|
1123534
|
18 G 1.5 | 18.0 | 259.2 | 589 | |
|
1123535
|
25 G 1.5 | 21.1 | 360 | 801 | |
|
1123537
|
3 G 2.5 | 10.1 | 72 | 189 | |
|
1123538
|
4 G 2.5 | 11.0 | 96 | 232 | |
|
1123539
|
5 G 2.5 | 12.1 | 120 | 279 | |
|
1123541
|
12 G 2.5 | 17.9 | 288 | 603 | |
|
1123544
|
3 G 4.0 | 11.4 | 115.2 | 260 | |
|
1123545
|
4 G 4.0 | 12.5 | 153.6 | 322 | |
|
1123546
|
5 G 4.0 | 13.7 | 192 | 387 | |
|
1123548
|
4 G 6.0 | 13.9 | 230.4 | 431 | |
|
1123549
|
5 G 6.0 | 15.8 | 288 | 533 | |
|
1123550
|
4 G 10.0 | 17.9 | 384 | 734 | |
|
1123553
|
4 G 25.0 | 25.2 | 960 | 1617 |
