ÖLFLEX® SERVO 7TCE
Multi-listed, flexible servo cable with optional pairs for brake and temperature sensor
ÖLFLEX® SERVO 7TCE – screened servo cable for fixed installation or occasional flexing with UL TC-ER.
- Servo motor and drive connections
- Wide application range (NFPA 70/NEC)/ compliance with NFPA 79 for industrial machinery
- EMC-compliant
Benefits
- One common cable for multiple circuits
- Multi-standard certification reduces part varieties and saves costs
- Cost-saving, easy installation due to omission of closed raceways (suitable for open wiring)
- Low capacitance design enables longer cable connection between frequency converter and motor
- UL TC-ER and c(UL) CIC/TC approved
Application range
- Connecting cable between servo controller and motor
- For fixed installation or applications with occasional movements
- Class 1 Division 2 per NEC Articles 336, 501
- Plant engineering
- Industrial machinery and machine tools
Product features
- Oil-resistant according to UL OIL RES I & II
- Flame-retardant according to CSA FT4
UL Vertical-Tray Flame Test - -40°C Cold Bend; -25°C Cold Impact; 90°C Wet or Dry
- Sunlight Resistant; Direct Burial
Norm references / Approvals
- UL TC-ER (exposed run) per UL 1277
- Class 1 Division 2 per NEC Articles 336, 501
- Flexible Motor Supply Cable per UL 2277
- c(UL) CIC FT4 (18AWG – 14AWG);
cRU AWM I/II A/B FT4
Product Make-up
- Fine-wire, bare copper conductor
- Core insulation: XLPE
- Individual design depending on the item: power cores without or with one or two individually screened control core pairs twisted together in short lay lengths
- Tinned-copper braiding
- Outer sheath: Specially formulated thermoplastic elastomer (TPE), orange
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000057
- ETIM 5.0 Class-Description: Low voltage power cable
Core identification code
- Power cores: black with marking U/L1/C/L+; V/L2; W/L3/D /L-; GN/YE protective conductor
- Optional designs with
one pair of control cores: black; white
Two pairs of control cores: black with white numbers: 5, 6, 7, 8
Certifications
- USA: UL TC-ER, Flexible Motor SupplyCanada: c(UL) CIC/TC FT4, cRU AWM I/II A/B FT4
Conductor stranding
- Fine wire
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 6 x outer diameter
Nominal voltage
- UL TC: 600V
UL Flexible Motor Supply: 1000V
c(UL) CIC/TC: 600V
cRU AWM: 1000V - IEC U0/U: 600/1000 V
Test voltage
- 2000 V
Protective conductor
- G = with GN-YE protective conductor
Temperature range
- Occasional flexing: -25°C to +90°C
Fixed installation: -40°C to +90°C
| Article number | Number of cores and mm² per conductor |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 700730 | 4 G 1,5 | 9.8 | 87.81 | 143 |
| 700731 | 4 G 2,5 | 11 | 132.46 | 199 |
| 700732 | 4 G 4 | 12.8 | 199.43 | 286 |
| 700733 | 4 G 6 | 14.1 | 281.29 | 373 |
| 700734 | 4 G 1,5 + (2 x 1,5) | 12.6 | 147.34 | 240 |
| 700735 | 4 G 2,5 + (2 x 1,5) | 13.3 | 190.5 | 301 |
| 700736 | 4 G 4 + (2 x 1,5) | 15.8 | 259.12 | 432 |
| 700737 | 4 G 6 + (2 x 1,5) | 17 | 354.22 | 496 |
| 700738 | 4 G 1,0 + 2 x (2 x 1,0) | 13.2 | 166.69 | 277 |
| 700739 | 4 G 1,5 + 2 x (2 x 1,0) | 13.9 | 187.53 | 314 |
| 700740 | 4 G 2,5 + 2 x (2 x 1,0) | 15.5 | 229.2 | 387 |
| 700741 | 4 G 4 + (2 x 1,0) + (2 x 1,5) | 17 | 325.94 | 487 |
| 700742 | 4 G 6 + (2 x 1,0) + (2 x 1,5) | 18.1 | 409.29 | 574 |
