Cáp Tín Hiệu LAPP KABEL UNITRONIC® LiYY BK | Chính Hãng – Ngoài Trời – Giá Tốt Nhất

UNITRONIC® LiYY BK

Data cable w/ colour code per DIN 47100, Black/ UV-resistant/ Outdoor use

UNITRONIC® Low-freq PVC data cable DIN 47100 Flexible (0.34 mm² multi-wire) Flame retardant, Instrumentation Control Automation, Black UV-resistant Outdoor use

  • The classic for multi-functional use – in black
  • UV resistant/ Outdoor use
  • CPR: Article number choice under www.lappkabel.com/cpr

Suitable for outdoor use UV-resistant

CE Fire

Benefits

  • Space-saving installation due to small cable diameters
  • Multifunctional application possibilities
  • Depending on the quantity, the outer sheath can also be produced in other colours to match your application needs
  • Outdoor use according to European standards

Application range

  • UNITRONIC® LiYY is also used as a control and signal cable in electronics of computer systems, electronic control equipment, office machines, balances, etc.
  • Dry or damp rooms
  • Occasional flexing
  • Outdoor use according to European standards

Product features

  • Despite the large number of cores, LiYY data cables have small outer diameters
  • Flame-retardant according IEC 60332-1-2
  • UV resistant according to EN 50525-1
  • Ozone-resistant

Norm references / Approvals

  • Based on VDE 0812

Product Make-up

  • Fine-wire/multi-wire (0.34 mm²) strand made of bare copper wires
  • Core insulation made of PVC
  • Outer sheath made of PVC
    Outer sheath colour: black

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000104
  • ETIM 5.0 Class-Description: Control cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000104
  • ETIM 6.0 Class-Description: Control cable

Core identification code

  • DIN 47100 without colour repetition, refer to Appendix T9

Mutual capacitance

  • Approx. 120 nF/km

Inductivity

  • approx. 0.65 mH/km

Conductor stranding

  • Stranded, fine-wire
    0.34 mm²: 7-wire

Minimum bending radius

  • Occasional flexing: 10 x outer diameter
  • Fixed installation: 4 x outer diameter

Temperature range

  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C

Note:

  • Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon request.
  • Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related surcharges.
  • Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
  • Packaging size: coil ≤ 30 kg or ≤ 250 m, otherwise drum
  • Please specify the preferred type of packaging (e.g. 1 x 500 m drum or 5 x 100 m coils).
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Article number Number of cores and mm² per conductor Outer diameter [mm] Copper index [kg/km] Weight [kg/km]
1030200 2 x 0.14 3.2 2.7 13
1030201 3 x 0.14 3.4 4.05 16
1030202 4 x 0.14 3.6 5.4 18
1030203 5 x 0.14 3.9 6.72 22
1030204 7 x 0.14 4.2 9.45 28
1030205 8 x 0.14 4.9 10.2 35
1030206 10 x 0.14 5.2 13.5 41
1030207 12 x 0.14 5.6 16.2 48
1030208 14 x 0.14 5.8 18.9 52
1030209 16 x 0.14 6.1 21.6 59
1030210 20 x 0.14 7 27 70
1030211 25 x 0.14 7.8 33.6 87
1030212 36 x 0.14 8.6 48.6 126
1030213 37 x 0.14 8.9 49.7 118
1030214 40 x 0.14 9.3 54 139
1030215 50 x 0.14 10.4 67.5 170
1030217 2 x 0.25 3.8 4.8 18
1030218 3 x 0.25 4 7.2 22
1030219 4 x 0.25 4.3 9.6 26
1030220 5 x 0.25 4.7 12 31
1030221 6 x 0.25 5.1 14.4 42
1030222 7 x 0.25 5.1 16.8 42
1030223 8 x 0.25 6.2 19.2 49
1030224 10 x 0.25 6.8 24 58
1030225 12 x 0.25 7 28.8 67
1030226 14 x 0.25 7.3 33.6 75
1030227 16 x 0.25 7.7 38.4 84
1030228 18 x 0.25 8.1 43.2 93
1030229 20 x 0.25 8.6 48 102
1030230 25 x 0.25 9.6 60 134
1030231 30 x 0.25 10.3 72 155
1030232 32 x 0.25 10.7 76.8 164
1030233 36 x 0.25 11.1 86.4 182
1030234 37 x 0.25 11.4 88.8 185
1030235 40 x 0.25 12 96.1 200
1030236 50 x 0.25 12.9 120 257
1030237 2 x 0.34 4.2 6.6 25
1030238 3 x 0.34 4.4 9.9 31
1030239 4 x 0.34 4.8 13.1 43
1030240 5 x 0.34 5.5 16.5 53
1030241 6 x 0.34 5.9 19.6 53
1030242 7 x 0.34 5.9 22.8 62
1030243 8 x 0.34 7.1 26.1 73
1030244 10 x 0.34 7.6 32.6 82
1030245 12 x 0.34 7.8 39.1 102
1030246 14 x 0.34 8.2 45.7 109
1030247 16 x 0.34 8.7 52 127
1030248 20 x 0.34 9.6 65.2 159
1030249 21 x 0.34 10.4 68.6 167
1030250 25 x 0.34 11.2 81.6 190
1030251 30 x 0.34 11.6 98 226
1030252 36 x 0.34 12.5 118 284
1030253 40 x 0.34 13.5 131 317
1030254 50 x 0.34 15 163 407
1030255 2 x 0.5 4.7 9.6 30
1030256 3 x 0.5 5 14.4 39
1030257 4 x 0.5 5.6 19.2 49
1030258 5 x 0.5 6.1 24 65
1030259 7 x 0.5 6.9 33.6 82
1030260 8 x 0.5 8 38.4 90
1030261 10 x 0.5 8.6 48 117
1030262 12 x 0.5 8.9 58 133
1030263 16 x 0.5 10.2 77 170
1030264 20 x 0.5 11.4 96 214
1030265 25 x 0.5 12.7 120 265
1030266 30 x 0.5 13.2 144 304
1030267 40 x 0.5 15.8 192 392
1030268 2 x 0.75 5.1 14.4 48
1030269 3 x 0.75 5.6 21.6 57
1030270 4 x 0.75 6.1 28.8 69
1030271 5 x 0.75 6.9 36 78
1030272 7 x 0.75 7.5 50 112
1030273 8 x 0.75 8.7 58 126
1030274 10 x 0.75 9.4 72 149
1030275 12 x 0.75 10.1 86 176
1030276 16 x 0.75 11.2 115 218
1030277 20 x 0.75 12.4 144 274
1030278 25 x 0.75 14 180 320
1030279 2 x 1.0 5.6 19.2 55
1030280 3 x 1.0 5.9 29 70
1030281 4 x 1.0 6.4 38.4 79
1030282 5 x 1.0 7.3 48 98
1030283 2 x 1.5 6.2 29 74
1030284 3 x 1.5 6.8 43 89
1030285 4 x 1.5 7.4 58 105
