Cáp Tín Hiệu LAPP KABEL UNITRONIC® LiYCY BK | Chính Hãng – Chống Nhiễu – Ngoài Trời – Giá Tốt Nhất

UNITRONIC® LiYCY BK

Shielded data cable with colour code acc. to DIN 47100, Black/ UV resistant/ Outdoor use

UNITRONIC® Shielded PVC data cable DIN 47100 Flexible (0.34 mm² multi-wire) Flame retardant, Instrumentation Control Automation, Black UV-resistant Outdoor use

  • The classic for multi-functional use – in black
  • UV resistant/ Outdoor use
  • CPR: Article number choice under www.lappkabel.com/cpr

Suitable for outdoor use Interference signals UV-resistant

CE Fire

Benefits

  • Overall braid minimises electrical
    interference
  • Multifunctional application possibilities
  • Outdoor use according to European standards

Application range

  • Screened cables with small dimensions are suitable for use in computer systems, insturmentation technology, office equipment, balances.
  • Dry or damp rooms
  • Outdoor use according to European standards

Product features

  • Flame-retardant according IEC 60332-1-2
  • UV resistant according to EN 50525-1
  • Ozone-resistant

Norm references / Approvals

  • Based on VDE 0812

Product Make-up

  • Fine-wire/multi-wire (0.34 mm²) strand made of bare copper wires
  • Core insulation made of PVC
  • Tinned-copper braiding
  • Outer sheath made of PVC
    Outer sheath colour: black

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000104
  • ETIM 5.0 Class-Description: Control cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000104
  • ETIM 6.0 Class-Description: Control cable

Core identification code

  • DIN 47100 without colour repetition, refer to Appendix T9

Mutual capacitance

  • C/C: approx. 120 nF/km
    C/S: approx. 160 nF/km

Inductivity

  • approx. 0.65 mH/km

Conductor stranding

  • Stranded, fine-wire
    0.34 mm²: 7-wire

Minimum bending radius

  • Occasional flexing: 15 x outer diameter
  • Fixed installation: 6 x outer diameter

Temperature range

  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C

Note

  • Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon request.
  • Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related surcharges.
  • Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
  • Packaging size: coil ≤ 30 kg or ≤ 250 m, otherwise drum
  • Please specify the preferred type of packaging (e.g. 1 x 500 m drum or 5 x 100 m coils).
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Article number Number of cores and mm² per conductor Outer diameter [mm] Copper index [kg/km] Weight [kg/km]
1030450 2 x 0.14 3.9 12 20
1030451 3 x 0.14 4.1 13 28
1030452 4 x 0.14 4.3 14.3 33
1030453 5 x 0.14 4.6 15.5 38
1030454 6 x 0.14 4.9 18.2 38
1030455 7 x 0.14 4.9 19 49
1030456 8 x 0.14 5.8 21.2 56
1030457 10 x 0.14 6.1 28.5 66
1030458 12 x 0.14 6.3 30.4 78
1030459 14 x 0.14 6.7 32 80
1030460 15 x 0.14 6.9 37.8 86
1030461 16 x 0.14 7 43 90
1030462 18 x 0.14 7.3 48.8 104
1030463 20 x 0.14 7.7 53.9 116
1030464 21 x 0.14 7.9 55.5 121
1030466 25 x 0.14 8.5 63 149
1030467 28 x 0.14 8.5 66.1 153
1030468 30 x 0.14 8.7 69 158
1030469 36 x 0.14 9.3 83 183
1030470 40 x 0.14 10.4 87.5 210
1030471 44 x 0.14 10.7 110.5 225
1030472 50 x 0.14 11.1 122.5 195
1030473 2 x 0.25 4.5 16 32
1030474 3 x 0.25 4.7 21 37
1030475 4 x 0.25 5 24 41
1030476 5 x 0.25 5.6 29 51
1030477 6 x 0.25 6 30 58
1030478 7 x 0.25 6 37 60
1030479 8 x 0.25 7.1 42 73
1030480 10 x 0.25 7.5 46 82
1030481 12 x 0.25 7.7 53 98
1030482 14 x 0.25 8 59 99
1030483 15 x 0.25 8.3 61 111
1030484 16 x 0.25 8.4 64 124
1030485 18 x 0.25 8.8 83 143
1030486 20 x 0.25 9.3 88 136
1030487 21 x 0.25 9.6 93 161
1030488 25 x 0.25 10.7 114 172
1030489 28 x 0.25 10.8 126 181
1030490 32 x 0.25 11.4 138 203
1030491 36 x 0.25 11.8 148 220
1030492 40 x 0.25 12.7 157 248
1030493 50 x 0.25 13.8 178 318
1030494 61 x 0.25 15 205 365
1030495 2 x 0.34 4.9 21 37
1030496 3 x 0.34 5.1 27 42
1030497 4 x 0.34 5.7 28 52
1030498 5 x 0.34 6.2 30 66
1030499 6 x 0.34 6.8 45 64
1030500 7 x 0.34 6.8 48 76
1030501 8 x 0.34 7.8 52 94
1030502 10 x 0.34 8.3 74 105
1030503 12 x 0.34 8.5 80 123
1030504 14 x 0.34 8.9 86 154
1030505 15 x 0.34 9.2 90 155
1030506 16 x 0.34 9.4 94 160
1030507 18 x 0.34 10.2 103 173
1030508 20 x 0.34 10.7 112 192
1030509 21 x 0.34 11.1 116 199
1030510 25 x 0.34 11.9 135 259
1030511 28 x 0.34 12 153 280
1030512 30 x 0.34 12.3 159 291
1030513 32 x 0.34 13 165 305
1030514 36 x 0.34 13.4 179 331
1030515 40 x 0.34 14.8 200 365
1030516 50 x 0.34 15.9 235 431
1030517 2 x 0.5 5.6 29 47
1030518 3 x 0.5 5.9 38 55
1030519 4 x 0.5 6.3 43 70
1030520 5 x 0.5 7 51 79
1030521 6 x 0.5 7.6 59 90
1030522 7 x 0.5 7.6 65 99
1030523 8 x 0.5 8.7 70 135
1030524 10 x 0.5 9.3 88 139
1030525 12 x 0.5 9.6 99 177
1030526 18 x 0.5 11.8 134 239
1030527 20 x 0.5 12.1 149 276
1030528 25 x 0.5 13.7 211 352
1030529 30 x 0.5 14.5 230 397
1030530 2 x 0.75 6 38 53
1030531 3 x 0.75 6.3 49 65
1030532 4 x 0.75 7 58 79
1030533 5 x 0.75 7.6 67 109
1030534 7 x 0.75 8.2 100 112
1030535 10 x 0.75 10.5 130 187
1030536 12 x 0.75 10.8 154 218
1030537 18 x 0.75 13 195 327
1030538 25 x 0.75 15.3 280 454
1030539 30 x 0.75 15.8 312 486
1030540 2 x 1.0 6.3 43 72
1030541 3 x 1.0 6.8 56 90
1030542 4 x 1.0 7.3 68 109
1030543 5 x 1.0 8 79 126
1030544 7 x 1.0 8.6 118 162
1030545 10 x 1.0 11.1 140 228
1030546 12 x 1.0 11.4 168 259
1030547 18 x 1.0 13.4 252 389
1030548 25 x 1.0 16.2 335 517
1030549 2 x 1.5 7.1 58 90
1030550 3 x 1.5 7.5 74 115
1030551 4 x 1.5 8.1 108 129
1030552 5 x 1.5 8.8 129 176
1030553 7 x 1.5 9.5 164 220
1030554 12 x 1.5 12.7 254 376
1030555 18 x 1.5 15.3 350 519
1030556 25 x 1.5 17.9 550 901
