UNITRONIC® LiYY (TP) BK

Data cable with DIN 47100 colour code and twisted pairs, Black/ UV resistant/ Outdoor use

UNITRONIC® – Low-frequency PVC data cable, DIN 47100 colour code, Twisted Pairs, Flame retardant, Instrumentation Control Automation, Outdoor use (black sheath)

  • The classic for multi-functional use – in black
  • TP = twisted pair
  • UV resistant/ Outdoor use

Suitable for outdoor use UV-resistant

CE Fire

Benefits

  • Decoupling of circuits by means of
    twisted-pair (TP) design (crosstalk effects)
  • Outdoor use according to European standards

Application range

  • Electronic devices tend to leave little room for installing cables, meaning short travel distances and small bending radii are required. This cable ideally meets these requirements.
  • Dry or damp rooms
  • Outdoor use according to European standards

Product features

  • Twisted in pairs to reduce decoupling. As a result, additional screening is often not required.
  • Flame-retardant according IEC 60332-1-2
  • UV resistant according to EN 50525-1
  • Ozone-resistant

Norm references / Approvals

  • Based on VDE 0812

Product Make-up

  • Fine-wire strand made of bare copper wires
  • Core insulation made of PVC
  • TP structure
  • Outer sheath made of PVC
    Outer sheath colour: black

Classification ETIM 5

  • ETIM 5.0 Class-ID: EC000104
  • ETIM 5.0 Class-Description: Control cable

Classification ETIM 6

  • ETIM 6.0 Class-ID: EC000104
  • ETIM 6.0 Class-Description: Control cable

Core identification code

  • DIN 47100, refer to Appendix T9

Mutual capacitance

  • Approx. 120 nF/km

Inductivity

  • approx. 0.65 mH/km

Conductor stranding

  • Fine copper wire strands

Minimum bending radius

  • Occasional flexing: 10 x outer diameter
  • Fixed installation: 4 x Outer diameter

Temperature range

  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C

Note

  • Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon request.
  • Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related surcharges.
  • Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
  • Packaging size: coil ≤ 30 kg or ≤ 250 m, otherwise drum
  • Please specify the preferred type of packaging (e.g. 1 x 500 m drum or 5 x 100 m coils).
  • Photographs and graphics are not to scale and do not represent detailed images of the respective products.
Article number Number of cores and mm² per conductor Outer diameter [mm] Copper index [kg/km] Weight [kg/km]
1030400 2 x 2 x 0.14 4.5 5.4 25
1030401 3 x 2 x 0.14 5 8 32
1030402 4 x 2 x 0.14 5.6 10.7 38
1030403 5 x 2 x 0.14 5.8 13.4 45
1030404 6 x 2 x 0.14 6.3 16.1 51
1030405 10 x 2 x 0.14 8.1 26.9 77
1030407 16 x 2 x 0.14 9.2 43 110
1030408 2 x 2 x 0.25 5.7 9.6 38
1030409 3 x 2 x 0.25 6.3 14.4 48
1030410 4 x 2 x 0.25 7 19.2 59
1030411 6 x 2 x 0.25 7.9 28.8 80
1030412 8 x 2 x 0.25 9.3 38.4 98
1030413 2 x 2 x 0.5 7.3 19.2 72
1030414 3 x 2 x 0.5 8.1 28.8 83
1030415 4 x 2 x 0.5 8.8 38.4 115
1030416 8 x 2 x 0.5 12.3 76.8 206
1030417 10 x 2 x 0.5 13.3 96 247
