UNITRONIC® LiYCY (TP) BK
Shielded data cable, twisted pairs, DIN 47100 colour code, Black/UV-resistant/Outdoors
UNITRONIC® LiYCY (TP) BK: Low-frequency PVC data cable DIN 47100 Twisted pairs Flame retardant Shielded, Instrumentation Control, Black, UV resistant, Outdoors
- TP = twisted pair
- The classic for multi-functional use – in black
- UV resistant/ Outdoor use
Benefits
- Decoupling of circuits by means of
twisted-pair (TP) design (crosstalk effects) - Overall braid minimises electrical
interference - Outdoor use according to European standards
Application range
- Can be used multifunctional in electronics of computer systems, electronic control equipment, office machines, balances, etc.
- Dry or damp rooms
- Outdoor use according to European standards
Product features
- Good protection against capacitive interference from electric fields (e.g. power cable)
- Flame-retardant according IEC 60332-1-2
- UV resistant according to EN 50525-1
- Ozone-resistant
Norm references / Approvals
- Based on VDE 0812
Product Make-up
- Fine-wire strand made of bare copper wires
- Core insulation made of PVC
- TP structure
- Tinned-copper braiding
- Outer sheath made of PVC
Outer sheath colour: black
Classification ETIM 5
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC000104
- ETIM 6.0 Class-Description: Control cable
Core identification code
- DIN 47100, refer to Appendix T9
Mutual capacitance
- C/C: approx. 120 nF/km
C/S: approx. 160 nF/km
Inductivity
- approx. 0.65 mH/km
Conductor stranding
- Fine copper wire strands
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 6 x outer diameter
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
Note
- Unless specified otherwise, the shown product values are nominal values. Detailed values (e.g. tolerances) are available upon request.
- Copper price basis: EUR 150/100 kg. Refer to catalogue appendix T17 for the definition and calculation of copper-related surcharges.
- Please find our standard lengths at: www.lappkabel.de/en/cable-standardlengths
- Packaging size: coil ≤ 30 kg or ≤ 250 m, otherwise drum
- Please specify the preferred type of packaging (e.g. 1 x 500 m drum or 5 x 100 m coils).
- Photographs and graphics are not to scale and do not represent detailed images of the respective products.
| Article number | Number of cores and mm² per conductor | Outer diameter [mm] | Copper index [kg/km] | Weight [kg/km] |
| 1030600 | 2 x 2 x 0.14 | 5.3 | 18.5 | 39 |
| 1030607 | 3 x 2 x 0.14 | 5.8 | 23 | 48 |
| 1030601 | 4 x 2 x 0.14 | 6.2 | 26.6 | 54 |
| 1030602 | 6 x 2 x 0.14 | 7.1 | 48.5 | 81 |
| 1030609 | 8 x 2 x 0.14 | 8.2 | 53.7 | 97 |
| 1030603 | 10 x 2 x 0.14 | 8.7 | 59 | 110 |
| 1030604 | 12 x 2 x 0.14 | 8.9 | 66 | 142 |
| 1030605 | 16 x 2 x 0.14 | 10.2 | 79 | 154 |
| 1030608 | 20 x 2 x 0.14 | 11.3 | 97 | 184 |
| 1030606 | 25 x 2 x 0.14 | 12.5 | 113 | 238 |
| 1030610 | 2 x 2 x 0.25 | 6.3 | 28 | 51 |
| 1030611 | 3 x 2 x 0.25 | 7.1 | 39.6 | 68 |
| 1030612 | 4 x 2 x 0.25 | 7.6 | 44.9 | 81 |
| 1030613 | 6 x 2 x 0.25 | 8.5 | 69.5 | 115 |
| 1030614 | 8 x 2 x 0.25 | 10.3 | 76.9 | 130 |
| 1030615 | 10 x 2 x 0.25 | 11 | 102 | 158 |
| 1030616 | 12 x 2 x 0.25 | 11.3 | 120 | 190 |
| 1030617 | 16 x 2 x 0.25 | 12.5 | 146.5 | 238 |
| 1030618 | 25 x 2 x 0.25 | 16.1 | 205 | 344 |
| 1030619 | 2 x 2 x 0.5 | 7.9 | 48.1 | 93 |
| 1030620 | 3 x 2 x 0.5 | 8.7 | 73.7 | 116 |
| 1030621 | 4 x 2 x 0.5 | 9.4 | 82 | 127 |
| 1030622 | 6 x 2 x 0.5 | 11.1 | 110 | 198 |
| 1030623 | 8 x 2 x 0.5 | 13.1 | 139 | 259 |
| 1030624 | 12 x 2 x 0.5 | 14.9 | 198.3 | 354 |
| 1030625 | 16 x 2 x 0.5 | 16.5 | 240 | 459 |
| 1030626 | 2 x 2 x 0.75 | 8.5 | 58 | 106 |
| 1030627 | 3 x 2 x 0.75 | 9.4 | 84 | 140 |
| 1030628 | 4 x 2 x 0.75 | 10.7 | 108 | 169 |
| 1030632 | 5 x 2 x 0.75 | 11.1 | 126 | 215 |
| 1030629 | 6 x 2 x 0.75 | 12.1 | 146 | 246 |
| 1030630 | 8 x 2 x 0.75 | 14.7 | 180 | 290 |
| 1030631 | 12 x 2 x 0.75 | 16.2 | 261 | 456 |
| 1030633 | 2 x 2 x 1.0 | 9 | 84 | 142 |
