“11005140” Cáp Tín Hiệu RS485 Helukabel UL2919 1x2x24AWG | Chính Hãng – Chống Nhiễu – Giá Tốt Nhất
Low Frequency Data Transmission Cables
HELUKABEL HELUDATA for low frequency data transmission , UL style 2919
Thương hiệu/ Brand-name: HELUKABEL
Mã hàng/ Part number: 11005140
Tiết diện lõi dẫn/ Conductor size: 1x2x24AWG # 0.2mm2 – 0.25mm2
Số lõi/ Pair Number: 1Pair – xoắn 1 cặp 2 sợi / 2Cores – 2 lõi
Xuất xứ/ Origin: Malaysia
Vỏ ngoài / Sheath: Vỏ PVC chống bén cháy IEC 60332-1-2
Vỏ ngoài / Sheath color: Mầu Xám
Nhiệt độ hoạt động tối đa/ Temperature rating: –30°C to + 80°C
HELUKABEL HELUDATA UL 2919 (RS 485) 1x2x24AWG
for use as Data Highway in RS 232, RS 422 and RS 485
Technical data
- PVC to UL-Style UL-Style 2919
- Temperature range
-30°C to + 80°C - Operating peak voltage
(not for power applications)
30 V - Test voltage
1000 V - Insulation resistance
min. 2 GOhm x km - Capacitance
C / C: approx. 42 pF/m
C / S: approx. 76 pF/m - Inductance
approx. 0,65 mH/km - Characteristic impedance
120 ohm
Cable structure
- Multi-wire strands of tinned copper wires / Lõi đồng mạ thiếc
- Core insulation of PE / Cách điện lõi bằng PE
- Cores twisted together / Lõi xoắn với nhau
- Aluminium / Mylar screening / Chống nhiễu lá nhôm
- Tinned annealed copper drain-wire / Dây thoát nhiễu bằng đồng mạ thiếc
- Tinned annealed copper braiding / Bện chống nhiễu lưới đồng mạ thiếc
- PVC outer sheath / Vỏ bọc bên ngoài PVC
- Colour: pebble grey, RAL 7032 / Màu sắc: xám cuội, RAL 7032
Properties
- 100% screen coverage, offers optimum protection against external interference at medium and high frequencies
- Low capacitance, double screened
- Excellent shielding against internal and external interference
- 100% độ phủ lá nhôm, bảo vệ tối ưu chống lại sự can thiệp bên ngoài ở tần số trung bình và cao
- Điện dung thấp, hai lớp chống nhiễu
- Chống nhiễu tuyệt đối chống lại sự can thiệp bên trong và bên ngoài
Application
This cable is suitable for wiring of data systems with high transmission rates. It is designed for use as Data Highway (DH) RS 232, RS 422, and RS 485 interface which is suitable for use as control and instrumentation cables. The cable is suitable for flexible and static laying in dry and damp locations.
Cáp này thích hợp để đi dây hệ thống dữ liệu với tốc độ truyền tải cao. Nó được thiết kế để sử dụng như giao diện RS 232, RS 422 và RS 485 của Đường dữ liệu (DH), phù hợp để sử dụng làm cáp điều khiển và thiết bị đo đạc. Cáp thích hợp để đặt linh hoạt và tĩnh ở những vị trí khô và ẩm ướt.
Hệ thống báo trộm/ Security Alarm System |
Hệ thống âm thanh/ Public Alarm System |
Hệ thống báo cháy/ Fire Alarm System |
Hệ thống kiểm soát cửa ra vào/ Access Control System |
Hệ thống giám sát xe GPRS |
Hệ thống giữ xe tự động |
Part no. | No.cores x cross-sec. mm² |
Outer Ø approx. mm |
Cop. weight kg / km |
Weight approx. kg / km |
11005140 | 1x2x24 AWG | 5,9 | 21,33 | 46 |
