LS-MP-UC6-RJ45-CV-WB | Hạt Mạng LS-VINA Unshield RJ45 Modular plug, Wire Snap type Modular plug Category 6 With Boot (OD 6.2mm) Fast installation of snap type | Chính Hãng – Giá Tốt Nhất
Hãng sản xuất : LS Simple
Xuất xứ : China
Description
– Unshielded RJ45 8P8C Modular Plug
– Compatible with LS UTP Category 6 Cable
(Category 6 channel performance with assembly)
– Complies with CFR 47 part 68.5. (Connector standard)
– Wire insertion guide structure in housing
– No accessory included except boot – LS unique design short type boot (optional)
– Easy to check the type by embossed engraving on boot
– Transparent color housing & boot
Application
• Horizontal Distribution & Backbone Cabling
• 4/16 Mbps Token Ring (IEEE 802.5)
• 10/100/1000BASE-T (IEEE 802.3)
• 155 Mbps ATM
• 100Mbps TP-PMD
• ISDN, ADSL
• Analog & Digital voice (VoIP) and video
• Full broadband and baseband video
Part Numbers
| Description | Part Number |
| Category 6 Unshielded RJ45 Modular Plug, Guide all-in-one type, Transparent, without boot |
LS-MP-UC6-RJ45-CV |
| Category 6 Unshielded RJ45 Modular Plug, Guide all-in-one type, Transparent, with boot |
LS-MP-UC6-RJ45-CV-WB |
Technical Details
| Item | Unit | Specification |
| FEATURE | ||
| Category | ANSI/TIA-568.2-D (Category 6) | |
| Meet | CFR title 47 Part 68.5 and IEC 60603-7 | |
| Wiring scheme | T568A/T568B | |
| ELECTRICAL | ||
| Current Rating | Amps | 1.5 |
| Insulation Resistance | Mega‐ohm | > 500 |
| Contact Resistance | milli‐ohm | < 20 |
| Dielectric Strength | VAC(RMS) | 1000 |
| Rated Voltage, Current | VAC max. | < 30 at 1.5A |
| MECHANICAL | ||
| Insertion Life | Mating cycles | 750 |
| Pull Force | N | 20 (89) |
| Temperature | ℃ | -40~85 |
| Humidity | % (RH) | 10 ~ 90 |
| Insulation hole diameter | m | 1.1mm |
| PHYSICAL | ||
| Plug Housing | High-impact Polycarbonate (PC), UL 94V-2 rated transparent | |
| Contact Blade | Brass, plated with 50 micro inches thick hard gold over nickel underplate on contact area 3-prong IDC | |
| Boot | High-impact Polycarbonate (PC), UL 94V-2 rated transparent |
Drawing
Packing
| Part no. | Packing | |||
| Polybag (140*220mm) |
inner box (345*145*145mm) |
Outer Box (455*310*370mm) |
Pallet | |
| LS-MP-UC6-RJ45-CV | 100EA /Polybag |
1500EA (15 bags) | 9000EA (6 inner boxes) |
24 boxes |
| LS-MP-UC6-RJ45-CV-WB | 50EA /Polybag |
750EA (15 bags) | 4500EA (6 inner boxes) |
24 boxes |
Polybag design
Inner box design
Outer box design
