ApusTM Cat.6 UTP
ApusTM Cat.6 UTP Data Cable

Features
HDCS®
ApusTM indoor and outdoor Cat.6 UTP cables are designed for unshielded cabling systems. HDCS® ApusTM Cat.6
cables exceed requirements of TIA 568-C.2 and ISO/IEC11801- 2nd-Edition with significant margins on all parameters. Cables are available in different jacket materials of various flame-retardant levels.

Construction
Construction: 4×2×AWG23
Conductor: AWG 23 Solid copper
Insulation: HDPE
Core: 4 twist pairs
Sheath: PVC, LSZH or PE
Colour: Grey, Orange, and Black
Nominal Diameter: 6.3 mm

Application
ApusTM Cat.6 Data Cable for structured premise cabling transmits
voice, data and video signals. It supports current high-bandwidth
applications, and is especially suitable for applications of FastEthernet.
• VoIP
• ISDN
• Token ring
• 100 Mbps TP-PMD
• Analog and digital video
• TR-16 active and passive
• 155 Mbit /622Mbit /1.2 Gbit ATM
• 10baseT/100baseTX Fast /1000baseTX Gigabit Ethernet

Electrical Performance at 20ºC

DC resistance                                ≤9.38ohm/100m
Unbalanced resistance                  ≤5%
Unbalance capacitance                 ≤330pF/100m
Capacitance                                  ≤5.6nF/100m
Dielectric strength                         DC 1kv (3s No Fail)
Insulation resistance                     ≥5000Mohm.Km
Impedance                                    1-250MHz (100±15) ohm
250-600MHz (100±25) ohm
Delay skew                                   ≤45ns

Mechanical Performance at 20ºC

Bending radius
During installation (min.)         8×outer diameter
Installed (min.)                        4×outer diameter
Temperature range
During installation                  0ºC to +50ºC
Installed                                 -20ºC to +60ºC

High-Frequency Performance at 20ºC

Frequency
(MHz)
Attenuation
(dB/100m)
NEXT
(dB)
RL
(dB)
PSNEXT
(dB)
ELFEXT
(dB)
PSELFEXT
(dB)
ACR
(dB)
Propagation
delay
(ns/100m)
Max. Min. Min. Min. Min. Min. Min. Max.
1 2 74.3 20 72.3 67.8 64.8 72 570
4 3.8 65.3 23 63.3 55.8 52.8 61 552
8 5.3 60.8 24.5 58.8 49.7 46.7 55 546.7
10 6 59.3 25 57.3 47.8 44.8 53 545.4
16 7.6 56.2 25 54.2 43.7 40.7 49 543
20 8.5 54.8 25 52.8 41.8 38.8 46 542
25 9.5 53.3 24.3 51.3 39.8 36.8 44 541.2
31.25 10.7 51.9 23.6 49.9 37.9 34.9 41 540.4
62.5 15.4 47.4 21.5 45.4 31.9 28.9 32 538.6
100 19.8 44.3 20.1 42.3 27.8 24.8 25 537.6
150 24.7 41.7 18.9 39.7 24.3 21.3 16.9 536.9
200 29 39.8 18 37.8 21.8 18.8 10.8 536.5
250 32.8 38.3 17.3 36.3 19.8 16.8 5.5 536.3
300 35 37.5 17 35.5 19.2 15.5 2.5 536.1
600 53.1 33 15 32.5 11 9.5 -20 535.5

Characteristic Graph

Ordering Information

Order Number Description
CP11-141-12* ApusTM Cat.6 indoor UTP cable, CM, 305m (Box)
CP11-141-13 ApusTM Cat.6 indoor UTP cable, LSZH, 305m (Reel in box)
CP11-141-14* ApusTM Cat.6 indoor UTP cable, CMR, 305m (Box)
CP11-141-16* ApusTM Cat.6 outdoor UTP cable, PE, 305m (Reel)
CP12-141-11 ApusTM Cat.6 outdoor UTP cable, PE, 305m (Reel)
